DC Brush Worm Gear Motors 6V 12V 24V DC Motor With Gearbox

Name: DC Brush Worm Gear Motors 6V 12V 24V DC Motor With Gearbox
Brand: Dongguan Futeng Motor Co., Ltd
SKU: FT-46SGM370
Availability: InStock

Brand Name:	FUTENG
Model Number:	FT-46SGM370
MOQ:	1000 Pieces
Price:	Negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	8000 0000

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE/ROHS/FCC/REACH/ISO14001/ISO9001/ISO45001/IATF16949

Efficiency:

45%-53%

Speed(RPM):

2rpm-600rpm

Commutation:

Brush

Construction:

Permanent Magnet

Rated Power:

1-48w

Rated Voltage:

3-24v, 6v/12v/24v

Torque:

1-200kgf.cm, 20/28/21/27(g.cm)

Type:

Gear Motor

Usage:

Home Appliance, Cosmetic Instrument, Smart Home, Robot

Warranty:

3 Months ~ 1 Year

Geared Motor Model:

FT-46SGM370

Gear Box Size:

46*32mm

Rotating Speed:

5000/12000/6000/9000(rpm)

Current:

45/90/21/43(mA)

Output:

0.88/2.96/1.12/2.2(w)

Name:

Robot Electric Motor

Packaging Details:

Standard Export Carton & Customzied

Supply Ability:

8000 0000

Highlight:

DC Brush Worm Gear Motors

Brush Worm Gear Motors 6V

24V DC Motor With Gearbox

Product Description

Futeng Factory Wholesale 6volt 12v Dc Motor with Gearbox 24v Dc Brush Worm Gear Motors for Coin Sorting Robot

DC gear motors are widely used:

Robots, electronic locks, public bicycle locks, relays, electric glue guns, household appliances, 3D printing pens, electric toothbrushes, office equipment, massage health care, beauty and fitness equipment, medical equipment, toys, electric daily necessities, automotive automatic facilities, etc.

Motor Data
Motor Model		No Load			Load						Stall
	Motor Model	Rated Voltage	Speed	Current	Speed	Current	Output	Torque	Current	Torque
		V	(rpm)	(mA)	(rpm)	(mA)	(w)	(g·cm)	(mA)	(g·cm)
FT-370	6	5000	45	4200	240	0.88	20	1100	112
FT-370	12	12000	90	10300	520	2.96	28	2500	177
FT-370	24	6000	21	5100	110	1.12	21	440	126
FT-370	24	9000	43	7800	210	2.2	27	950	182

FAQ

Q1: Are you trading company or manufacturer?

A: We're factory. We specialize in micro dc motor and dc gear motor for more than 10years.

Q2: I can't find a suitable motor on your website, can you customize the motor for me?

A: Yes, we can customize a suitablemotor according to our customer's requirements.

Q3: Do you have certificates for the motors?

A: Yes. we have CE. FCC, ISO, etc. lf you have the other certificates requirement,we can apply it for you.

Q4: How is your Quality Control?

A: We have professional checking staff on every production line process. After finishing the
whole motor, we have the entire quality machine to test the motor. Such as Hardness Tester, 2.5D image Tester, Salt Spray Chamber,LifeTester, Temperature Test Machine, and Noise tester etc.
